EX Series 24V Digital Input Module CC-LINK Network Adapter EX-1040 with IP20 Protection for Reliable Industrial Automat

EX Series Digital Input Module CC-LINK Adapter EX-1040


Product nameCC-Link Adapter
Address setting1~64
CableCC-Linkspecial cable
Transmission distance1200m(max)
Bus rate156kpbs,625kpbs,2.5Mbps,
5Mbps,10Mbps
EX System power input24V(18 ~ 36V)
EX System provides current2A(Max)
IO port power supply input24V(±20%)
IO port current output10A(Max)
Expand the number of I/ O32
Input/output maximum bytes48 bytes /48 bytes
DimensionsLength, width and height:
90mm*67mm*34mm
Temperature rangeWorking temperature:0 ~ 55℃
Storing temperature:-20 ~ +85℃
Relative humidity95% No Condensation
Protection gradeIP20
